Opqo supports setting Maximo configuration information by scanning a QR code containing the necessary details.
The QR code must contain a serialized JSON object, with the following properties:
| Name | Data Type | Notes |
| host | String | Required. The hostname of the Maximo environment to connect to. Should contain only the hostname. |
| name | String | Optional. The name of the connection to display to the user. |
| type | String | Optional. "PROD" for production environments, any other value for non-production The value for non-production environments is displayed to the user. |
| ssl | Boolean | Optional. Whether the connection should use SSL. If not specified, the default is: true. |
| port | Integer | Optional. The port to connect to the Maximo server on. Must be a valid TCP port. If not specified, will use the standard HTTP/S ports (80/443), depending on whether ssl is used or not. |
| utcert | Boolean | Optional. Whether to accept untrusted/self-signed SSL certificates when connecting to Maximo and ssl is enabled. If not specified, the default value is "false". |
| app | String | Optional. The Maximo app context. If not specified, the default value is "maximo". |
| api | String | Optional. The Maximo API context for the REST API. If not specified, the default value is "oslc" |
| auth | String | Optional. The authentication method to use when connecting to Maximo. Valid values are:
"standard": For Maximo environments configured with internal authentication, LDAP (BASIC auth) or Forms authentication. This also includes MAS development environments. "maxauth": For Maximo environments configured with internal authentication. This option will only send the MAXAUTH header for authentication. Typically not required, as "standard" should suffice. "ldap": For Maximo environments configured with LDAP authentication. This option will only send the HTTP BASIC authentication header for authentication. Typically not required, as "standard" should suffice. "saml": For Maximo environments configured with SAML authentication. If not specified, the default value is "standard" |
| csrf | Boolean | Optional. Whether Opqo should request a CSRF protected session when connecting to Maximo. CSRF protected sessions are required when applying updates to Maximo, when the system property mxe.oslc.enforcecsrf is enabled. Note that Opqo will automatically upgrade a non-CSRF session to a CSRF protected session if an update fails by disconnecting and establishing a new connection. However, setting this value to "true" if your Maximo environment requires it will be more efficient. If not specified, the default value is "false". |
Example
An example QR code and content is shown below, for connecting to the Opqo demo environment:
 | {
"host": "opqo-demo.sharptree.io",
"ssl": true,
"name": "Opqo Demo"
} |
Please do not hesitate to contact us or create a support ticket if you have questions or require our assistance.
